| 參數Parameters | 型號Model | YTO-03AF | YTO-05AF | YTO-08AF | YTO-10AF | YTO-12AF | YTO-15AF | YTO-20AF | YTO-25AF | YTO-30AF | YTO-40AF | ||
| 制冷量 | Kcal/h | 7216 | 11997 | 18748 | 24089 | 29059 | 37969 | 50809 | 61671 | 74992 | 97679 | ||
| Cooling capacity | Kw/h | 8.39 | 13.95 | 21.8 | 28.01 | 33.79 | 44.15 | 59.08 | 71.71 | 87.2 | 113.58 | ||
| 運行控制方式 Control Type |
溫度數顯微電腦控制器 Digital temperature display microcomputer controller |
||||||||||||
|
溫控范圍 Temperature range |
+3℃~常溫(0℃以下可訂制) 3℃-Room temperature(Below 0℃can be customized) |
||||||||||||
| 電源Power supply | 3N-380V-50HZ(非標電源可訂制) | ||||||||||||
|
安全保護裝置 Safety Protection Device |
過載保護、逆缺相保護、高/低壓保護、防凍保護等 Overload.InversePhase.High/LowPressure.AntifreezeProtection.etc |
||||||||||||
| 總功率Total power | KW | 2.57 | 4.31 | 7.65 | 9.9 | 11.4 | 13.7 | 18.8 | 22.59 | 27.4 | 37.6 | ||
| 最大運行電流Maximu mRunming Curent | A | 7.2 | 12.07 | 21.42 | 27.72 | 31.92 | 38.36 | 52.64 | 63.25 | 76.72 | 105.28 | ||
|
制冷劑 Refrireant |
名稱Name | R22(R410A R407C R134A) | |||||||||||
| 充注量Charge | KG | 2.1 | 3.5 | 5.6 | 6.9 | 8.4 | 10.5 | 14 | 17.4 | 21 | 28 | ||
|
控制方式 Controltyp |
外平衡式熱力膨脹閥 Extctnal Balanced Thcrmostatic Expansion Valvc |
||||||||||||
|
壓縮機 Compresson |
類型Type | 全封閉渦旋式或活塞式Hermetic scrolltype or piston | |||||||||||
| 功率KW | 2.2 | 3.75 | 6 | 7.5 | 9 | 11 | 15 | 18.75 | 22 | 30 | |||
|
冷凝器 condensator |
型式Form |
高效銅管套波紋型鋁翅片 Efficient brass sets corrugated aluminum fin |
|||||||||||
| 散熱風機 Blower | 風量M3/h | 3000 | 5000 | 8000 | 10000 | 12000 | 15000 | 20000 | 25000 | 30000 | 40000 | ||
| 功率KW | 0.28 | 36 | 0.9 | 0.9 | 1.2 | 1.2 | 1.6 | 1.64 | 2.4 | 3.6 | |||
|
蒸發器 Evaporator |
型式Type |
高效銅管套波紋型鋁翅片 Efficient brass sets corrugated aluminum fin |
|||||||||||
|
冷風風機 Air cooler Fan |
風機功率KW | 0.2 | 0.25 | 0.75 | 0.75 | 1.5 | 1.5 | 22 | 2.2 | 3 | 4 | ||
| 冷風風量M3h | 370 | 800 | 1280 | 1600 | 1920 | 2400 | 3200 | 4000 | 4800 | 6400 | |||
| 冷風風壓Pa | 340 | 700 | 780 | 780 | 890 | 890 | 1000 | 1000 | 1000 | 1000 | |||
| 出風管徑mm | 100 | 100 | 160 | 160 | 160 | 200 | 200 | 200 | 250 | 250 | |||
|
機器尺寸 Machine size |
長L/mm | 940 | 1050 | 1400 | 1400 | 1600 | 1600 | 1800 | 2000 | 2400 | 2350 | ||
| 寬W/mm | 555 | 610 | 720 | 720 | 800 | 800 | 900 | 1000 | 1000 | 1550 | |||
| 高H/mm | 1060 | 1260 | 1410 | 1410 | 1580 | 1680 | 1750 | 1850 | 1950 | 1800 | |||
| 機組重量Unit weight KG | 150 | 170 | 270 | 350 | 380 | 520 | 590 | 790 | 900 | 1100 | |||
